Description
LH88AB High-intensity aviation obstruction lights are used to mark buildings that may cause damage to aircraft. Combines with advanced LED, optical and system control technology to meet the most demanding applications. Suitable for obstacles with a height of 150 meters. Suitable for high salinity corrosion area.
Features
- Aluminum alloy die-cast shell, yellow electrostatic powder coating surface, antivibration, corrosion-resistant.
- Light source using LED technology, long life, low energy consumption, high efficiency.
- Anti-UV, shock-resistant PC housing; flammability level: UL94V-2.
- Professional EMC design, anti-electromagneticinterference.
- Waterproof silicone seal structure.
- Wind load level:≥240km/h.
Application & Model Code
Application
Suitable for obstacles with a height of 150 meters.
Suitable for high salinity corrosion area.
Model Code
LH88AB
High Intensity Aviation Obstruction Light LH88AB-HIA
Technical Parameters
Base
Product Name:
High Intensity Aviation Obstruction Light
Product Mode:
LH88AB
Input Voltage:
Power box @ DC48V AC200~240V AC100~130V Light head @ DC48V
Rated Power :
85 W @ 1 layer daytime
150 W @ 2 layers daytime
220 W @ 3 layers daytime
Frequency 5 : 0-60Hz(AC power box )
Surge Lightning Protection
IEC61000-4-5 L- L 6kV
IEC61000-4-5 L- G 6kV
Electrostatic discharge
IEC61000-4-2 Contact discharge 8kV
IP rate :
Light @ IP66 Power box @ IP65
Horizontal Beam : 120°
Vertical Beam :
5° Optics
Intensity
LH88FA@ 270,000 ± 25% cd FAA-L856
LH88FB@ 140,000 ± 25% cd FAA-L857
LH88AA@ 200,000 ± 25% cd ICAO-Type A
LH88AB@ 100,000 ± 25% cd ICAO-Type B
LH88CA@ 200,000 ± 25% cd CAAC-Type A
LH88CB@ 100,000 ± 25% cd CAAC-Type B
Horizontal Beam : 120°
Vertical Beam : 5° Flash Rate:
40FPM
Surge Lightning:
IEC61000-4-5 L- L 6kV
Protection:
IEC61000-4-5 L- G 6kV
Ambient humidity
0% ~ 90% RH(No condensation)
Operating temperature
-40˚C ~ +65˚C
Weight
6 Kg (One layer light head)
7.3 Kg (Junction box)
9.2 Kg (bracket)
40 Kg (AC power box)
11 Kg (DC power box)
IEC61000-4-5 L- G 6kV
